8.11 Control initial setting 2 level (l.2)
8-47
Setting data
● Related setting data
"Linear current output
∗ type" (Control initial setting level) (P.8-42)
"Output 1 output type", "Output 3 output type" (Control initial setting
level) (P.8-42)
• Use these settings to assign event input functions.
• If the same setting is selected for different event input assignments,
the event input for which ON/OFF is determined last will be effective.
Note that when the power is turned on and the same bank No.
assignment is repeated, the event input with the higher number is
given priority.
• SP modes (Remote/Local) of CH2 to CH4 are disabled.
● Related information
"5.7 Using event input" (P.5-29)
Reference
Reference
Event input 1 allocation
Event input 2 allocation
Event input 3 allocation
ev.1
ev.2
ev.3
Event input 4 allocation
Event input 5 allocation
Event input 6 allocation
ev.4
ev.5
ev.6
l.2
Function
Setting
Setting range Units
Default value
Disable (0)
Write via communication OFF/ON (1)
CH1 Bank No. (Bit 0) (2)
CH1 Bank No. (Bit 1) (3)
CH1 Bank No. (Bit 2) (4)
CH1 Run/Stop (5)
CH1 Auto/Manual (6)
CH1 SP mode (Remote/Local) (7)
CH2 Bank No. (Bit 0) (8)
CH2 Bank No. (Bit 1) (9)
CH2 Bank No. (Bit 2) (10)
CH2 Run/Stop (11)
CH2 Auto/Manual (12)
CH2 SP mode (Remote/Local) (13)
Similarly,
CH3 (14 to 19)
CH4 (20 to 25)
− 0
When the control mode is set to cascade control, assign the
following CH2 operation commands:
• CH2 Run/Stop (11)
• CH2 Auto/Manual (12)
• CH2 SP mode (Remote/Local) (13) Cascade open
Cascade open / closed
Important
Reference
Reference
