Setting data
• These settings are used to select the type of alarms 1 through 4.
● Related setting data
"Bank
∗ alarm value ∗ " (Bank setting level) (P.8-28)
"Bank
∗ alarm upper limit ∗ ", "Bank ∗ alarm lower limit ∗ " (Bank
setting level) (P.8-29)
"Auxiliary output ∗ assignment" (Control initial setting 2 level) (P.8-48)
"Alarm ∗ latch" (Alarm setting level) (P.8-55)
"Alarm
∗ hysteresis" (Alarm setting level) (P.8-56)
"Standby sequence restart" (Alarm setting level) (P.8-57)
Alarm 1 type
Alarm 2 type
Alarm 3 type
Alarm 4 type
alt1
alt2
alt3
alt4
Alarm is assigned to auxiliary output.
CH
l.3
Function
Setting
Setting data Setting range Units Default value
Alarm 1 type
Alarm 2 type
Alarm 3 type
Alarm 4 type
0: No alarm function
1: Upper- and lower-limit alarm
2: Upper limit alarm
3: Lower limit alarm
4: Upper- and lower-limit range alarm
5: Upper- and lower-limit alarm with
standby sequence
6: Upper limit alarm with standby
sequence
7: Lower limit alarm with standby
sequence
8: Absolute-value upper-limit alarm
9: Absolute-value lower-limit alarm
10: Absolute-value upper-limit alarm
with standby sequence
11: Absolute-value lower-limit alarm
with standby sequence
−
2: Upper
limit
alarm
Reference
Reference
