8.12 Alarm setting level (l.3)
8-55
Setting data
• When this setting is set to "ON", a latch function is added to the
alarm function. Once an alarm goes on, the alarm output is held on
until the power is turned off. Note that the latch is canceled if you
change to setting area 1.
• When the alarm output is set to close in alarm, closed output is held,
and when set to open in alarm, open output is held.
• After changing an alarm 1 to 3 latch setting, a software reset must
be executed or the power turned off and on to make the new setting
take effect.
● Related setting data
"Bank
∗ alarm ∗" (Bank setting level) (P.8-28)
"Bank
∗ alarm upper limit ∗ ", "Bank ∗ alarm lower limit ∗ "(Bank
setting level) (P.8-29)
"Auxiliary output
∗
assignment" (Control initial setting 2 level) (P.8-48)
"Alarm ∗ type" (Alarm setting level) (P.8-54)
"Alarm
∗ hysteresis" (Alarm setting level) (P.8-56)
"Standby sequence restart" (Alarm setting level) (P.8-57)
Alarm 1 latch
Alarm 2 latch
Alarm 3 latch
Alarm 4 latch
a1lt
a2lt
a3lt
a4lt
Alarm is assigned to auxiliary output and
alarm type is set to other than "No alarm".
CH
l.3
Function
Setting
Setting data Setting range Units
Default value
Alarm 1 latch
Alarm 2 latch
Alarm 3 latch
Alarm 4 latch
off: Disable
on : Enable
− off: Disable
Reference
Reference
