Section 8 Setting data
8-56
Setting data
• These settings are used to enable hysteresis for alarms 1, 2, 3, and
4.
● Related setting data
"Bank
∗ alarm ∗" (Bank setting level) (P.8-28)
"Bank
∗ alarm upper limit ∗ ", "Bank ∗ alarm lower limit" (Bank
setting level) (P.8-29)
"Auxiliary output
∗
assignment" (Control initial setting 2 level) (P.8-48)
"Alarm ∗ type" (Alarm setting level) (P.8-54)
"Alarm
∗ latch" (Alarm setting level) (P.8-55)
"Standby sequence restart" (Alarm setting level) (P.8-57)
Alarm 1 hysteresis
Alarm 2 hysteresis
Alarm 3 hysteresis
Alarm 4 hysteresis
alh1
alh2
alh3
alh4
Alarm is assigned to auxiliary output and
alarm type is set to other than "No alarm".
CH
l.3
Function
Setting
Setting data Setting range Units
Default
value
Alarm 1 hysteresis
Alarm 2 hysteresis
Alarm 3 hysteresis
Alarm 4 hysteresis
0.01 to 99.99 %FS 0.02
Reference
Reference
