8.15 Advanced function setting level (l.adf)
8-69
Setting data
• When one or both PF keys are set to monitor/setting item, "Monitor/
setting item 1" through "Monitor/setting item 5" of each key must be
set to the desired values among 0 to 19 below.
• Each time a PF key is pressed, the display scrolls to the next
monitor/setting item in order from "Monitor/setting item 1" to "Monitor
setting item 5".
● Related setting data
"PF1 setting", "PF2 setting" (Advanced function setting level) (P.8-68)
Setting
Setting data Setting range Units Default value
PF1 setting
off : Disable
run : Run
stop: Stop
r-s : Run/Stop toggle
allr: Run all
alls: Stop all
at : AT Execute/Cancel
toggle
bank: Bank scroll
a-m : A key
pfdp: Monitor/setting item
− a-m: A key
PF2 setting −
r-s: Run/
Stop toggle
PF1 monitor/setting item 1 to
PF1 monitor/setting item 5
PF2 monitor/setting item 1 to
PF2 monitor/setting item 5
pf1.1 to
pf1.5
pf2.1 to
pf2.5
PF key set to monitor/setting item
CH
l.adf
Function
Setting
Setting Setting range Units
Default
value
PF1 Monitor/
setting item 1
0: Disable
1: PV/SP/Bank
Configurable (SP)
2: V/SP/MV
Configurable (SP)
3: PV/DV Monitor only
4: Proportional band (P) Configurable
5: Integral time (I) Configurable
6: Derivative time (D) Configurable
7: Alarm 1 Configurable
8: Alarm upper limit 1 Configurable
9: Alarm lower limit 1 Configurable
10: Alarm 2 Configurable
11: Alarm upper limit 2 Configurable
12: Alarm lower limit 2 Configurable
13: Alarm 3 Configurable
14: Alarm upper limit 3 Configurable
15: Alarm lower limit 3 Configurable
16: Alarm 4 Configurable
17: Alarm upper limit 4 Configurable
18: Alarm lower limit 4 Configurable
19: Bank No. Configurable
−
1
PF1 Monitor/
setting item 2
0
PF1 Monitor/
setting item 3
0
PF1 Monitor/
setting item 4
0
PF1 Monitor/
setting item 5
0
PF2 Monitor/
setting item 1
1
PF2 Monitor/
setting item 2
0
PF2 Monitor/
setting item 3
0
PF2 Monitor/
setting item 4
0
PF2 Monitor/
setting item 5
0
Reference
Reference
