Omron E5AR - MANUAL 2 User Manual

Setting list
A-9
Appendix
* As follows when read in setting area 1:
• RSP input error : Clear
• Potentiometer error : Clear
• Display range exceeded : Clear
• Input error : Clear
• Control output (heating), control output (cooling) : Clear
• Alarm 1, Alarm 2, Alarm 3, Alarm 4 : Clear
•AT : Clear
• Run/Stop : ON (stop)
• Auto/Manual : Hold previous value
• SP mode, MV tracking : Update
• Control output (heating), control output (cooling) : Update
* Control output (heating) and control output (cooling) are respectively open output and close output
during position proportional control.
* Control output (heating) and control output (cooling) are normally OFF during linear output.
* The control output heating type and/or control output cooling type is off when the corresponding output
is pulse voltage output.
Output
type
Operation state
31 30
00000
29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 Bit position
Free
Free
Free
Free
Write mode
EEPROM
Setting area
AT Execute/Cancel
Run/Stop
Write via communication
Auto/Manual
SP mode
MV tracking
Free
Status 0 (OFF)
OFF
OFF
OFF
OFF
Backup
RAM = "EEPROM"
Setting area 0
AT stopped
Run
OFF (plohibited)
Auto
Local SP (LSP)
OFF
OFF
1(ON)
−
−
−
−
RAM write
RAM ≠ "EEPROM"
Setting area 1
AT run in progress
Stop
ON (permitted)
Manual
RSP
ON
−
Control output
(heat side) type
Control output
(cool side) type
inear current
output
inear current
output
Pulse voltage
output
Pulse voltage
output
