Appendix
A-16
Appendix
CompoWay/F
Setting data
Attributes
Variable type
Address Address
Modbus
Character Setting (monitor) value Character
Default
value
Decimal point
position
Units
Set value
CA 0036
003F
0046
0047
0A6C
0A7E
0A8C
0A8E
7.p
8.p
8.aut
8.aut
Same as display range of "Present value (PV)" *2
Temperature input: Specified range of sensor
input
Analog input: -110% to 110% of scaling range
However, maximum is H'FFFFB1E1 to
H'0001869F (-19999 to 99999) *4
1450.0
1650.0
EU
EU
According to input type
According to input type
CH
CH
CH
CH
CH
CH
PID 7 proportional band
~
PID 8 proportional band
~
PID 8 automatic selection range upper limit (PV)
PID 8 automatic selection
range upper limit (DV)
*1 .... Not displayed in HMI.
*2 .... Specified upper limit of input
The maximum is -19999 to 99999.
*3 .... Temperature input: Specified range width of sensor input
Analog input: -110% to 110% of scaling range width
The maximum is -19999 to 99999.
*4 .... The upper limit of the automatic selection range of PID set No. 8 is fixed at 999.99% FS for internal data (this can be changed but it will not affect operation).
*5 .... Selected PID set number.
CompoWay/F
Setting data
Attributes
Variable type
Address Address
Modbus
Character Setting (monitor) value Character
Default
value
Decimal point
position
Units
Set value
CB 0000
0001
0002
0003
0004
0005
0006
0007
0010
0023
0024
0037
0B00
0B02
0B04
0B06
0B08
0B0A
0B0C
0B0E
0B20
0B46
0B48
0B6E
si1.1
si2.1
so1.1
so2.1
si1.2
si2.2
so1.2
so2.2
fi01.1
fi20.1
fo01.1
fo20.1
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
H'FFFFF831 to H'0000270F (-1.999 to 9.999)
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
-1.999
to
9.999
0.000
1.000
0.000
1.000
0.000
1.000
0.000
1.000
0.000
0.000
0.000
0.000
−*1
−*1
−*1
−*1
−*1
−*1
−*1
−*1
−*1
−*1
−*1
−*1
3
3
3
3
3
3
3
3
3
3
3
3
Common
Common
Common
Common
Common
Common
Common
Common
Common
Common
Common
Common
Straight-line approximation 1 input 1
Straight-line approximation 1 input 2
Straight-line approximation 1 output 1
Straight-line approximation 1 output 2
Straight-line approximation 2 input 1
Straight-line approximation 2 input 2
Straight-line approximation 2 output 1
Straight-line approximation 2 output 2
Broken-line approximation 1 input 1
~
Broken-line approximation 1 input 20
Broken-line approximation 1 output 1
~
Broken-line approximation 1 output 20
Approximation setting level
"H' -" indicated in set values (monitor values) are values set by communication (monitor).
*1 .... These are set values for each of the operation functions. Set normalized values based on the input data for the operation function.
When a straight-line approximation is included in the input stage of input type K -200.0 to 1300.0°C, -200.0 to 1300.0°C is equivalent
to the normalized value 0.000 to 1.000.
