66
SECTION 5
Specifications
F210
Setup Manual
SECTION 5
Troubleshooting and Maintenance
Console
F160-KP
The switch on the back of the F160-KP must be set to “ENABLE”.
Specification
Current consumption
Approx. 10mA
Vibration
resistance
10 to 150 Hz; half-amplitude: 0.35 mm; maximum acceleration: 50 m/s
2
,10 times for 8 minutes
each in 3 directions
Shock resistance 150 m/s
2
, 3 times each in 6 directions
Ambient temperature
Operating: 0 to 50°C (with no condensation) Storage: -25 to 65°C (with no condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Ambient environment
No corrosive gases
Degree of protection
IEC60529 IP20 (in-panel)
Minimum bending radius
75mm
Materials Body: ABS
Cable sheathing: Heat-resistant PVC
Connector: PC and PBT
Weight Approx. 160g
(Unit:mm)
'06
5*+(6
'5% 64+)
(
(
(
(
(
(
(
(
(
&+5#$.'''0#$.'
These keys will be disabled if the switch is
set to “DISABLE”.
ENABLE
