10
Function Blocks Section 2-1
2-1-4 Reset and Restart Function Blocks
2-1-5 Connector Function Blocks
Redundant
Input
Generic Two-
input Monitor-
ing
Monitors for discrepancies in two input signals. Not supported. 74
Single Beam
Safety Sensor
Single Beam
Safety Sensor
Monitoring
Monitors the input signal of an OMRON E3ZS/
E3FS Single-beam Safety Sensor.
Not supported. 74
Non-Contact
Door Switch
Monitoring
Non-Contact
Door Switch
The Non-Contact Door Switch function block
monitors the status of an OMRON D40A or
D40Z Non-contact Door Switch.
Not supported. 74
Safety Mat
Monitoring
Safety Mat Monitors the status of an OMRON UM Safety
Mat.
Not supported. 75
Name Notation on
Function List
Icon Details Support by
NE1A-series
Controllers
Page
Reset Reset Outputs ON if the reset signal is correctly input
while the input condition is ON. This function
block can be used to prevent equipment from
starting automatically.
All unit versions 76
Restart Restart Performs the same operation as a Reset func-
tion block. The icon is different.
Refer to 3-6-1 Reset for a description of func-
tions and setting parameters.
All unit versions 78
Name Notation on
Function List
Icon Details Support by
NE1A-series
Controllers
Page
Multi Connector Multi Connec-
tor
Outputs the status of the input signals. NE1A-series Con-
trollers with unit
version 1.0 or
later
79
Routing Routing Distributes an input signal to multiple signals. All unit versions 80
Name Notation on
Function List
Icon Details Support by
NE1A-series
Controllers
Page
To Next Page
