Omron G9SP Series

38
Timer/Counter Function Blocks Section 3-4
Incrementing Counter:
2. Manual Reset
Decrementing Counter:
Decrementing Counter:
3-4-5 Up-Down Counter
Basic Function Increments the counter on the rising edge of an up count input and decre-
ments the counter on the rising edge of a down count input.
Diagram
IDLE to RUN
Input
Set value
Count
Output
Enable
IDLE to RUN
Input
Set value
Count
Output
Enable
Reset
0
IDLE to RUN
Input
Set value
Count
Output
Enable
Reset
Up Count Input
Down Count Input
Reset
