Logic Function Blocks Section 3-3
Truth Table for Six-input
AND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Seven-
input AND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Eight-input
AND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Output 1
0xxxxx 0
x0xxxx 0
xx0xxx 0
xxx0xx 0
xxxx0x 0
xxxxx0 0
111111 1
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Output 1
0xxxxxx 0
x0xxxxx 0
xx0xxxx 0
xxx0xxx 0
xxxx0xx 0
xxxxx0x 0
xxxxxx0 0
1111111 1
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1
0xxxxxxx 0
x0xxxxxx 0
xx0xxxxx 0
xxx0xxxx 0
xxxx0xxx
0
xxxxx0xx 0
xxxxxx0x 0
xxxxxxx0
0
11111111 1
