Omron G9SP Series

23
Logic Function Blocks Section 3-3
Truth Table for Five-input
OR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Six-input
OR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Seven-
input OR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Eight-input
OR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Input 1 Input 2 Input 3 Input 4 Input 5 Output 1
00000 0
1xxxx 1
x1xxx 1
xx1xx 1
xxx1x 1
xxxx1 1
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Output 1
000000 0
1xxxxx 1
x1xxxx 1
xx1xxx 1
xxx1xx 1
xxxx1x 1
xxxxx1 1
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Output 1
0000000 0
1xxxxxx 1
x1xxxxx 1
xx1xxxx 1
xxx1xxx 1
xxxx1xx 1
xxxxx1x 1
xxxxxx1
1
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1
00000000 0
1xxxxxxx 1
x1xxxxxx 1
xx1xxxxx 1
xxx1xxxx 1
xxxx1xxx 1
xxxxx1xx 1
xxxxxx1x 1
xxxxxxx1 1
