Omron G9SP Series

25
Logic Function Blocks Section 3-3
Truth Table for Five-input
NAND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Six-input
NAND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Seven-
input NAND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Eight-input
NAND Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Input 1 Input 2 Input 3 Input 4 Input 5 Output 1
0xxxx 1
x0xxx 1
xx0xx 1
xxx0x 1
xxxx0 1
11111 0
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Output 1
0xxxxx 1
x0xxxx 1
xx0xxx 1
xxx0xx 1
xxxx0x 1
xxxxx0 1
111111 0
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Output 1
0xxxxxx 1
x0xxxxx 1
xx0xxxx 1
xxx0xxx 1
xxxx0xx 1
xxxxx0x 1
xxxxxx0 1
1111111
0
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1
0xxxxxxx 1
x0xxxxxx 1
xx0xxxxx 1
xxx0xxxx 1
xxxx0xxx 1
xxxxx0xx 1
xxxxxx0x 1
xxxxxxx0 1
11111111 0
