Omron G9SP Series

27
Logic Function Blocks Section 3-3
Truth Table for Five-input
NOR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Six-input
NOR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Seven-
input NOR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Truth Table for Eight-input
NOR Evaluation
0: OFF, 1: ON, x: Either ON or OFF
Input 1 Input 2 Input 3 Input 4 Input 5 Output 1
00000 1
1xxxx 0
x1xxx 0
xx1xx 0
xxx1x 0
xxxx1 0
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Output 1
000000 1
1xxxxx 0
x1xxxx 0
xx1xxx 0
xxx1xx 0
xxxx1x 0
xxxxx1 0
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Output 1
0000000 1
1xxxxxx 0
x1xxxxx 0
xx1xxxx 0
xxx1xxx 0
xxxx1xx 0
xxxxx10 0
xxxxxx1
0
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Output 1
00000000 1
1xxxxxxx 0
x1xxxxxx 0
xx1xxxxx 0
xxx1xxxx 0
xxxx1xxx 0
xxxxx1xx 0
xxxxxx1x 0
xxxxxxx1 0
