Register No. Contents
002BH
Input Terminal Status
bit 0 Terminal S1 Closed
bit 1 Terminal S2 Closed
bit 2 Terminal S3 Closed
bit 3 Terminal S4 Closed
bit 4 Terminal S5 Closed
bit 5 to bit F Reserved
002CH
Drive Status 2
bit 0 During Run
bit 1 Zero Speed
bit 2 Speed Agree
bit 3 User Speed Agree
bit 4 Frequency Detection 1
bit 5 Frequency Detection 2
bit 6 Drive Ready
bit 7 During Undervoltage
bit 8 During Baseblock
bit 9 Frequency Reference from Operator Keypad
bit A Run Command from Operator Keypad
bit B Overtorque
bit C, D Reserved
bit E Fault
bit F Communication Timeout
002DH
Output Terminal Status
bit 0 Multi-Function Contact Output (terminal MA/MB-MC)
bit 1 to bit F Reserved
002EH to 0030H Reserved
0031H DC Bus Voltage, 1 Vdc units
0032H to 0033H Reserved
0034H Product Code 1 [ASCII], Product Type (J0 for J1000)
0035H to 003CH Reserved
003DH
Communications Error Contents
<2>
bit 0 CRC Error
bit 1 Data Length Error
bit 2 Reserved
bit 3 Parity Error
bit 4 Overrun Error
bit 5 Framing Error
bit 6 Timeout
bit 7 to bit F Reserved
003EH Reserved
003FH Output Frequency 0.01% units
0040H to 007EH
Used for various monitors U1-. Refer to U: Monitors on page 181 for parameter details.
007FH Alarm Code, Refer to Alarm Register Contents on page 204 for alarm codes.
0080H to 0097H
Used for monitors U2-. Refer to U: Monitors
on page 181 for parameter details and Refer to Fault History Contents
on page 203 for register value descriptions.
0098H High Word of Accumulated Operation Time Monitor (U4-01)
0099H Low Word of Accumulated Operation Time Monitor (U4-01)
009AH to 009BH Reserved
00ABH Drive Rated Current
00ACH to 00B5H Reserved
00B6H
Frequency Reference After
Soft-starter
0.01% units
00B7H Reserved
00B8H Frequency Reference 0.01% units
00B9H to 00BEH Reserved
00BFH oPE Error Number
C.10 MEMOBUS/Modbus Data Table
