00C0H
Fault contents 1
bit 0 Reserved
bit 1 Undervoltage (Uv1)
bit 2 Reserved
bit 3 Soft Charge Circuit Fault (Uv3)
bit 4, 5 Reserved
bit 6 Overcurrent (oC)
bit 7 Overvoltage (ov)
bit 8 Reserved
bit 9 Heatsink Overheat (oH1)
bit A Motor Overload (oL1)
bit B Drive Overload (oL2)
bit C Overtorque Detection 1 (oL3)
bit D, E Reserved
bit F Braking Resistor Overheat (rH)
00C1H
Fault contents 2
bit 0 External Fault at input terminal S3 (EF3)
bit 1 External Fault at input terminal S4 (EF4)
bit 2 External Fault at input terminal S5 (EF5)
bit 3 to 9 Reserved
bit A Input Phase Loss (PF)
bit B, C Reserved
bit D Digital Operator Connection Fault (oPr)
bit E EEPROM Write Error (Err)
bit F Reserved
00C2H
Fault contents 3
bit 0 MEMOBUS/Modbus Communication Error (CE)
bit 1 to 5 Reserved
bit 6 MEMOBUS/Modbus Communication Option External Fault (EF0)
bit 7 to E Reserved
bit F Hardware fault (includes oFx)
00C3H Reserved
00C4H
Fault contents 5
bit 0 Reserved
bit 1 External Fault 1, input terminal S1 (EF1)
bit 2 External Fault 2, input terminal S2 (EF2)
bit 3, 4 Reserved
bit 5 Current Offset Fault (CoF)
bit 6 to F Reserved
00C5H to 00C7H Reserved
00C8H
Alarm contents 2
bit 0 Undervoltage (Uv)
bit 1 Overvoltage (ov)
bit 2 Heatsink Overheat (oH)
bit 3 Reserved
bit 4 Overtorque 1 (oL3)
bit 5 Reserved
bit 6 Run Commands Input Error (EF)
bit 7 Drive Baseblock (bb)
bit 8 External Fault 3, input terminal S3 (EF3)
bit 9 External Fault 4, input terminal S4 (EF4)
bit A External Fault 5, input terminal S5 (EF5)
bit B to F Reserved
00C9H
Alarm contents 3
bit 0, 1 Reserved
bit 2 Digital Operator Connection Fault (oPr)
bit 3 MEMOBUS/Modbus Communication Error (CE)
bit 4 Reserved
bit 5 Serial Communication Transmission Error (CALL)
bit 6 Motor Overload (oL1)
bit 7 Drive Overload (oL2)
bit 8 to F Reserved
C.10 MEMOBUS/Modbus Data Table
202
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
