5 - 3
5 Inspection and Maintenance
Grid Connect Photovoltaic Inverter KP100L-OD- USER’S MANUAL
5-1 Inspection and Maintenance
5
Exchanging Fans (FAN Assembly)
The exchange of FAN in the state set up is possible.
(1) The screw in 4 places is removed, and the FAN Assembly is removed as shown in figure below.
(2) Remove the FAN Assembly from the main body of the product.
Functional lesion by injury and fire damage may possibly occur. Do not remove the MC cap
on the back of the product when you exchange the FAN Assembly.
WARNING
Screw (4 places)
