3 Operation
3 - 8
Grid Connect Photovoltaic Inverter KP100L-OD- USER’S MANUAL
3-3 Display transition
The display according to the state of the KP100L and the key operation is done after the KP100L starts. The
following show the image of the display transition.
Item Description
State display You can check operating state of KP100L.
Normal Display The display of state of KP100L. Refer to section " Normal Display" in "3-4" for detail.
Error Display The occurring error is displayed. Refer to section " Error Display" in "3-4" for detail.
Mode selection display You can select from this display to each mode of User's setup / Check Settings / Error
Logging.
mode of User's setup You can set the setup value. Refer to section " User Setting" in "3-5" for detail.
mode of Check Settings You can check the setup value. Refer to section "Setting confirmation" in "3-5" for detail.
mode of Error Logging You can confirm the error that occurred in the past.
Refer to section "Error Logging" in "3-5" for detail.
LCD Check Display You can check LCD. Refer to " 3-7" for detail.
Normal Display
Pac 3.69kW
1.23/1.23/1.23kW
Error Dis
p
la
y
Error occurs
Mode selection dis
p
la
y
ModeSelect
ErrLog [Setup] Che
ModeSelect
Setup [Check]ErrL
>>
ModeSelect
Check[ErrLog] Set
>> >>
mode of User’s setu
p
mode of Check Settings
mode of Error
State dis
p
la
y
Setup:Language
ENG
ErrLog:1.E1-0
No Utility
Check:Country
GER
LCD Check Dis
p
la
y
MODE
or
No oparation for 150second
<<<<<<
ENT
MODE
Error doesn’t
occur
for 5 second
Push the ENT key
Push the MODE key
for 5 second
Push the MODE key or
No operation for 150seconds
Fault E1-2
Grid 0V
ENT
MODE
ENT
MODE
■■■ V1.23 ■■■
■■■
KP100L ■■■
