Grid Connect Photovoltaic Inverter KP100L-OD- USER’S MANUAL
A-1 Error list
The table below shows the list of Error and the content of the display of each error.
Error code Content of error
Contents of display[3]
content of
display[2]
Mode(AUX_OUT1)
(Refer to P.74)
Error name error kind 1 2 3 4 5
E1-1 Over voltage (Grid) Grid OV Fault * *
E1-2 Under voltage (Grid) Grid UV Fault * *
E1-3 Over frequency (Grid) Grid OF Fault * *
E1-4 Under frequency (Grid) Grid UF Fault * *
E1-5 Islanding passive IslandingPassive Fault * *
E1-6 Islanding active IslandingActive Fault * *
E1-7 Over voltage instantly (Grid) OV instantly Fault * *
E1-8 Under voltage instantly (Grid) UV instantly Fault * *
E1-0 No Utility No Utility Fault * *
E2-1 Over voltage (DC) DCOverVolt Fault * * *
E2-3 Ground I fault Ground I fault Fault * * *
E2-4 Insulation resistance fault RISO fault Fault * * *
E3-1 Over Current (DC) OverDcCurr Failure * * *
E3-2 Over Current (AC) OverAcCurr Failure * * *
E3-3 DC Current Injection DcCurrInj Failure * * *
E3-4 Over temperature Over temperature Fault * * *
E4-1 Abnormality of comparison of
measurement 
(between Master CPU and Slave CPU))
CompMes CPU Failure
***
Abnormality of comparison of
measurement
(Power source)
CompMes PS Failure
***
Abnormality of comparison of
measurement 
(Circuit of grid frequency)
CompMes Freq Failure
***
Abnormality of comparison of
measurement 
(Circuit of grid voltage)
CompMes GridVolt Failure
***
Abnormality of comparison of
measurement 
(Circuit of DC and D/D)
CompMes DcVolt Failure
***
E4-2 Abnormity of efficiency Efficiency Fail Failure * * *
E4-3 Failure of inverter (Output AC current) InvFail CntrCur Failure * * *
E4-4 Abnormality of ROM version ROMver fault Fault
E4-5 Abnormality of power source PS fault Failure * * *
E4-6 Abnormality of eeprom's sum value EepromSumFailure Failure * * *
E4-7 Failure of eeprom EepromFailure Failure * * *
E5-1 Failure of relay (Grid relay) RelayFail Grid Failure * * *
Failure of relay (N phase relay) RelayFail N Failure * * *
Failure of relay (Relay for pre-charge) RelayFail Pre Failure * * *
E5-2 Communication error between Master
CPU and Slave CPU
CpuComFail M-S Failure
***
Communication error between Master
CPU and Display CPU
CpuComFail M-D Failure
***
