Grid Connect Photovoltaic Inverte KP100L-OD-USER’S MANUAL
Checking the Accessories
The follow items are included in the KP100L package. Check that all of the items shown in the package before
you start the installation.
The complete set of Accessories
Safekeeping of the Original Carton Box
Keep the original carton box and use it when you transport the KP100L for repair service etc.
Items Number Note
Mounting Screw 8
For installation of Mounting base plate
Snap Bushing 8
Tool of assistance when screw is stopped to hard wall
like concrete.
M4 x 12mm Screw with
plain washer and spring
washer
5
For fixation of product set up in Mounting base plate
(4 peaces are for mounting, a peace is for reserve)
M4 x 6mm Screw with plain
washer and spring washer
2
Spare screw to fix the cover foreside R
Rubber Bush
1
For connection of AC cable
1
For connection of AC cable
2
Spare rubber bush
For connection of AUX and communication
MC Caps
2
Caps for MC connection ( + )
These are attached to KP100L.
2
Caps for MC connection ( - )
These are attached to KP100L
KP100L
Mounting base plate QIG (Quick Install Guide)
Only KP100L-OD-EU/EU-T
User’ s Manual
Only KP100L-OD-KR
For KP100L-OD-EU/EU-T, PDF file is
provided.Consult your OMRON representative
to get PDF file
To Next Page
