1 Overview
Grid Connect Photovoltaic Inverte KP100L-OD-USER’S MANUAL
1-3 Appearance and Names of
Parts
1
1-3 Appearance and Names of Parts
(1) Fan
AC Cable Clamp
3-pairs of
DC Input plug
(MC4 connectors)
Communication
Cable Clamp
AUX Cable Clamp
Key
Display
Cover foreside R
(for Wiring)
Cover front
Cover foreside L
Fans
Heat sink
Fans
