Grid Connect Photovoltaic Inverte KP100L-OD-USER’S MANUAL
(2) 3-pairs of DC input plug (standard MC4 connectors):
Each input pair consists of positive and negative terminals, Refer to "2-4 Wiring".
(3) AC Output:
Delivering AC to the grid
DC Input plug ( - )
DC Input plug ( + )
DC1
DC2
DC3
L1 L2 L3 PEN
AC Cable Clamp
AC Terminal Block
