1 Overview
Grid Connect Photovoltaic Inverte KP100L-OD-USER’S MANUAL
1-3 Appearance and Names of
Parts
1
(4) AUX Interface
AUX Interface has the two relay output and the one photo coupler input.
(5) RS-232C or RS-485 Communication Interface:
The interface allows the communication with computer via RS-232C or RS-485.
(6) Display and Key
AUX Cable Clamp
Communication Cable Clamp
AUX Terminal Block
Communication Terminal Block
Key
Display
