Grid Connect Photovoltaic Inverte KP100L-OD-USER’S MANUAL
(5) Set it in product so that 4 places in the part where both sides of the mounting base plate are curved
may come outside of the heat sink.
(6) Set it up so that the 2 screws in the both sides of the heat sink may fall into the ditch of the mounting
base plate.
(7) Fix the heat sink and the mounting base plate by using bundled M4X12 with plane washer and spring
washer in 4 points. (Tightening torque: 1.5 to1.7 Nm)
