3 - 27
3 Operation
Grid Connect Photovoltaic Inverter KP100L-OD- USER’S MANUAL
3-6 Setting in Particular Countries
3
9
 Detect level of Each Country
The detect level (default value) of each country is the following. These level are set under consideration of
regulation value , tolerance, and detection time.
The detect level cannot be changed excluding the OF/UF level of Italy and the OV level of Germany.
*1 Before connecting the grid, it is examined if the voltage and frequency of the grid remains within the tolerance area
pursuant to VDE0126-1-1 4.2.1, 4,2,2 and 4.3 for 30 seconds. The connection and feeding cannot be carried out unless
voltage and frequency of the grid remain within the tolerance pursuant to VDE0126-1-1 4.2 and 4.3 for 5 seconds.
*2 Before connecting the grid, it is examined if the voltage and frequency of the grid remains within the tolerance for 30
seconds.
"The detect level" and "the detect time" of "OF" and "UF" of South Africa are the master value. In the design,
"OF", and "UF" are detected by following "the detect level" and "the detect time".
Set value item Germany Spain Italy France Greece Czech Denmark Portugal Turkey RSA
OV Level [V] 253.00 253.00 276.00 264.50 253.00 264.50 253.00 253.00 253.00 249.80
Time [s] 0.15 4.90 0.10 0.15 0.45 0.15 0.15 4.90 0.15 599.90
UV Level [V] 184.00 195.50 184.00 195.50 176.00 195.50 184.00 195.50 184.00 209.60
Time [s] 0.15 4.90 0.20 0.15 0.45 0.15 0.15 4.90 0.15 599.90
OF Level [Hz] 50.15 50.90 50.30 50.50 50.50 50.50 50.15 50.90 50.15 51.45
Time [s] 0.15 4.90 0.10 0.15 0.45 0.15 0.15 4.90 0.15 59.90
UF Level [Hz] 48.50 49.10 49.70 49.50 49.50 49.50 48.50 49.10 48.50 48.55
Time [s] 0.15 4.90 0.10 0.15 0.45 0.15 0.15 4.90 0.15 59.90
Reconnection
time [s]
5.5(*1) 180.5
(*2)
20.5 5.5(*1) 180.5
(*2)
5.5(*1) 5.5(*1) 180.5
(*2)
5.5(*1) 5.5(*1)
Set value item Level[Hz] Time[s]
OF 51.45 or more Within 59.9
51.95 or more Within 9.9
53.95 or more Within 0.9
UF 48.55 or less Within 59.9
48.05 or less Within 9.9
47.55 or less Within 5.9
46.05 or less Within 0.9
