Omron NT21 User Manual

2-3SectionMemory Tables
76
Support Tool values Stored Value
in decimal
Stored value
after start of
operation
Contents of
host words
Number
of
Words
Storage
Type
Stored value
before op-
eration
Input Value
(before
confirmation)
Stored Value
in decimal
Stored value
after start of
operation
Contents of
host words
Number
of
Words
Storage
Type
Stored value
before op-
eration
Input Value
(after
confirmation)
--- 43------21
61,441 61,441 0000 F001 BCD
1 1441 0000 05A1 1,441
,
,
2 61441 0000 F001 61,441
$F001 Binary
1 F001 FFFF F001 –4,095
$
y
2 0000 F001 0000 F001 61,441
65535 65,535 0000 FFFF BCD
1 5535 0000 159F 5,535
,
2 0006 5535 0000 FFFF 65,535
$FFFF Binary
1 FFFF FFFF FFFF –1
$
y
2 0000 FFFF 0000 FFFF 65,535
–1 –1 FFFF FFFF BCD
1 F001 FFFF FFFF –1
2 F000 0001 FFFF FFFF –1
$FFFF FFFF Binary
1 FFFF FFFF FFFF –1
$
y
2 FFFF FFFF FFFF FFFF –1
Numeral Table Memory Data before Start of Operation
1, 2, 3... 1. Initial value inputs at the Support Tool are written into the numeral memory
table entries as 2-word signed binary data regardless of the Storage Type or
Number of Words settings. (Even when the value is written in hexadecimal
with the $ prefix, it will be displayed in decimal at the Support Tool after the
input is confirmed.)
2. Before operation starts, the contents of the numeral memory table entries
are retained within the PT as 2-word signed binary data regardless of the
Storage Type or Number of Words settings.
Numeral Table Memory Data at the Start of Operation
3. When operation is started, the contents of numeral memory table entries are
written to words in the host first. At this point, data is converted and written as
described below according to the Storage Type or Number of Words set-
tings.
Storage
Type
Number
of words
Conversion and storage
BCD 1
The 2-word signed binary data is converted to BCD and
the least significant 4 digits are written. If the value is
negative, F and the least significant 3 digits are written.
BCD 2
The 2-word signed binary data is converted to BCD and
the 8 digits are written. If the value is negative, F and
the least significant 7 digits are written.
Binary 1
The least significant 4 digits of the 2-word signed binary
data are written as is.
Binary 2 The 2-word signed binary data is written as is.
4. After operation has started, the host words are read and the data is regularly
mirrored in the numeral memory table entries. The data is converted and
