Omron NX-ECC201 User Manual

9 - 31
9 Setting Up Slave Terminals
NX-series EtherCAT Coupler Unit User’s Manual (W519)
9-3 Assigning Variables
9
9-3-2 Assigning Device Variables to I/O Ports
 Registering Device Variables
You assign device variables to I/O ports in the I/O Map of the Sysmac Studio. The device variables
that you create are registered in the variable table.
 Device Variable Attributes
This section describes the attributes for the device variables that are used with the EtherCAT Slave Ter-
minal.
Registering Device Variables and Attributes
Attribute Specification method Changes to settings
Variable name There are three ways to assign a device variable.
• Select a registered variable from the variable table.
• Manually enter the device variable name.
• Automatically create the device variable name.
Variable names are automatically created using the fol-
lowing convention:
device_name+I/O_port_name
Possible.
Data type Specify the data type of the I/O port. You must also spec-
ify a data type of the same size as the data type of the I/O
port.
Not possible.
AT specification ECAT://node#[node_address.NX_Unit_number]/I/O_port
_name
Examples:
For an EtherCAT Coupler Unit whose node address is 10,
and a Digital Input Unit (NX-ID3317 Four-point Input Unit)
whose NX Unit number is 15:
ECAT://node#[10,15]/Input Bit 00 to
ECAT://node#[10,15]/Input Bit 03
Not possible.
Retain Not retained. Not possible.
Initial value None Possible.
Constant Do not specify a constant. Possible.
Network publish Do not publish. Possible.
