Appendices
A - 10
NX-series EtherCAT Coupler Unit User’s Manual (W519)
7 Place the Sysmac Studio offline. Remove the USB cable from the EtherCAT Slave Terminal and
turn ON the power to the master from the other manufacturer.
8 Use the software from the other manufacturer to read the I/O allocation settings (PDO Map Set-
tings) for the EtherCAT Slave Terminal.
9 Use the software from the other manufacturer to create the network configuration information
(ENI) based on the EtherCAT Slave Terminal information that was read in the previous step.
Download the network configuration information file to the master from the other manufacturer.
(This operation is called active configuration.)
10 Turn ON the Unit power supplies and I/O power supplies for the EtherCAT Slave Terminal, and
start communications.
This section provides supplementary information that applies when you connect an EtherCAT Slave
Terminal to a master from another manufacturer.
The node address setting will contain the value that is set in the software from the other manufacturer.
This section describes the I/O map.
PDO Groups
There are three groups of PDOs. These are described in the following table.
PDO Group Mapping Order
Mapping is performed in the following order of PDO groups: Coupler, Word, and then Bit. Within the
PDO groups that the NX Units belong to, mapping is performed in the order of the NX Unit numbers.
PDO Group Boundaries
The areas that are mapped for the PDO groups are aligned by word.
A-4-2 Supplementary Information for Connections with a Master from
Another Manufacturer
Node Address Setting
Switch setting Description
000 The node address is set to the value that is set in the software from another
manufacturer, and not the switch settings. (Setting range: 1 to 65535)
You can use the rotary switch and DIP switch settings as the Host Connect
ID. (Setting range: 0 to 199)
001 to 199
I/O Map
PDO group Description
Coupler This PDO group is for the EtherCAT Coupler Unit.
Word This PDO group is for NX Units that have I/O data entries in words.
Bit This PDO group is for NX Units that have I/O data entries in bits. NX Units that have PDO
entries (I/O entries) consisting of only BOOL data belong to this group.
