Omron NX-ECC201 User Manual

A - 59
Appendices
NX-series EtherCAT Coupler Unit User’s Manual (W519)
A-7 Version Information
A
A-7-1 Relationship between the Unit Versions of EtherCAT Coupler Unit and Sysmac Studio Ver- sions
A-7 Version Information
This section describes the relationship between the EtherCAT Coupler Unit version and the versions of
the Sysmac Studio and the NJ-series CPU Units.
The following table shows the relationship between the unit versions of the EtherCAT Coupler Unit and
the Sysmac Studio versions.
(Yes: Can be used. No: Cannot be used.)
The following table shows the relationship between the unit versions of the EtherCAT Coupler Unit and
the CPU Unit.
(Yes: Can be used. No: Cannot be used.)
Precautions for Correct Use
On the Select Device Tab Page in the project on the Sysmac Studio, select version 1.05 or later
for the CPU Unit version. You cannot use the EtherCAT Coupler Unit if you select 1.04 or earlier
for the Unit version.
A-7-1 Relationship between the Unit Versions of EtherCAT Coupler
Unit and Sysmac Studio Versions
Model number of EtherCAT Cou-
pler Unit
Unit Version
Sysmac Studio version
1.05 or lower 1.06
NX-ECC201 1.0 No Yes
A-7-2 Relationship between Unit Versions of EtherCAT Coupler Unit
and CPU Units
Model number of EtherCAT Cou-
pler Unit
Unit Version
Unit version of
NJ501-/NJ301- CPU Unit
1.04 or lower 1.05
NX-ECC201 1.0 No Yes
