Appendices
A - 34
NX-series EtherCAT Coupler Unit User’s Manual (W519)
• This object gives the Sysmac error status for the EtherCAT Slave Terminal.
• The assignments of bits in the Sysmac error status at subindex 01 hex are listed below. The applica-
ble bit is 0 (FALSE) if no error exists, or 1 (TRUE) if an error exists.
Bits 6 to 15: Reserved
Bit 5: Minor Fault
Bit 4: Observation
Bits 2 to 3: Reserved
Bit 1: Reserved
Bit 0: Reserved
Refer to Details of I/O Data in the EtherCAT Coupler Unit on page 9-16 for details on the Sysmac
error status.
• Subindex 02 hex is used to clear the Sysmac Error Status.
Write 01 hex to clear the Sysmac Error Status. If you write a value other than 01 hex, the command is
invalid and the abort code is returned.
When a read is performed, 00 hex is given.
• This object gives observation-level Controller events that are detected by the EtherCAT Slave Termi-
nal.
• Subindex 00 hex gives the number of observations that are detected by the EtherCAT Slave Termi-
nal.
A-5-8 Manufacturer-specific Object 1
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit
Data
attribute
Size Access
PDO
map-
ping
Com-
plete
access
2002 --- Sysmac Error --- --- --- --- --- --- --- Not pos-
sible.
00 Number of entries 02 hex 02 hex --- --- 1 byte
(U8)
RO Not
possi-
ble.
---
01 Sysmac Error Status 02 hex 00 to FF hex --- --- 1 byte
(U8)
RO Possi-
ble.
---
02 Sysmac Error Status
Clear
00 hex 00 to FF hex --- A 1 byte
(U8)
RW Not
possi-
ble.
---
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit
Data
attribute
Size Access
PDO
map-
ping
Com-
plete
access
2003 --- Sysmac Observation --- --- --- --- --- --- --- Possible.
00 Number of Observa-
tion
00 hex 00
to
80 hex
--- --- 1 byte
(U8)
RO Not
possi-
ble.
---
01 Observation 1 --- --- --- --- 12 bytes
(VS)
RO Not
possi-
ble.
---
---
*1
*1. Subindexes 02 to 7F hex are intentionally omitted from this table. The number after the object name for subindexes 02 to
7F hex are 2 to 127, and are assigned in ascending order. The data definitions, except for object names, are the same
as those for subindexes 01 and 80 hex.
--- --- --- --- --- --- --- --- ---
80 Observation 128 --- --- --- --- 12 bytes
(VS)
RO Not
possi-
ble.
---
