Omron NX-ECC201 User Manual

9 Setting Up Slave Terminals
9 - 16
NX-series EtherCAT Coupler Unit User’s Manual (W519)
The next section describes each data item in detail.
This section describes the I/O data in detail.
 NX Unit Registration Status
505th
Transmit
PDO
Mapping
Time Stamp of Syn-
chronous Input
This time stamp tells
when a synchronous
input occurred in the NX
Unit. Units: ns
ULINT 0 Timestamp of
Synchronous
Input
200A hex 01 hex
Time Stamp of Syn-
chronous Output
This time stamp tells
when a synchronous
output occurred in the
NX Unit. Units: ns
ULINT 0 Timestamp of
Synchronous
Output
200A hex 02 hex
512th
Transmit
PDO
Mapping
Sysmac Error Status This is the Sysmac
error status. It gives the
level of the error in the
EtherCAT Slave Termi-
nal.
BYTE 02 hex Sysmac Error
Status
Yes 2001 hex 01 hex
Details of I/O Data in the EtherCAT Coupler Unit
Data name Description
NX Unit Registration Status
15
This status tells whether the NX Units are registered in the Unit Configuration.
The status is acquired for as many NX Units as the numeric suffix at the end of
the data name. Select the I/O data with the appropriate numeric value based on
the number of NX Units that are mounted.
This status is given as an array of BOOL data. The subscript of the array corre-
sponds to the NX Unit number. A subscript of 0 indicates the EtherCAT Coupler
Unit.
Each bit has the following meaning.
TRUE: Registered
FALSE: Not registered
If the Unit configuration information is registered, the status is TRUE for each Unit
that is registered.
If the Unit configuration information was automatically created (with only the
actual Unit configuration information and no registered information), the status is
FALSE for all Units.
The status is TRUE for NX Units that are set as unmounted Units.
Each bit is updated at the following times.
• If the Unit Configuration Information Is Registered:
The status changes to TRUE when the system is started.
The status changes to FALSE when the configuration information is cleared.
• If the Unit Configuration Information Is Automatically Created:
The status changes to TRUE when the configuration information is confirmed.
The status is always FALSE if the Unit configuration information is automati-
cally created.
NX Unit Registration Status
31
NX Unit Registration Status
63
NX Unit Registration Status
125
I/O entry
mapping
name
Data name Function Data type Default I/O port name
Regis-
tered by
default
NX object
Index
number
Subin-
dex
number
