11 EtherCAT Coupler Unit Functions
11 - 4
NX-series EtherCAT Coupler Unit User’s Manual (W519)
Security These functions of the NJ-series CPU Unit are designed
to protect assets and prevent incorrect operation.
11-4 Security on
page 11-10,
NJ-series CPU Unit
Software User’s
Manual (Cat. No.
W501)
Operation Authority Verifi-
cation
You can set operation authorities to restrict the opera-
tions that can be performed when the Sysmac Studio is
used to access the EtherCAT Slave Terminal through a
connection to the CPU Unit.
Event Logs This function records events, such as errors and status
changes, that occur in the EtherCAT Slave Terminal.
11-5 Event Logs on
page 11-12
Clear All Memory This function initializes the entire EtherCAT Slave Termi-
nal or specified Units from the Sysmac Studio.
11-6 Clearing All
Memory on page
11-20
Restarting This function allows you to apply changes to settings with
the Sysmac Studio or through special instructions, with-
out cycling the Unit power supply.
11-7 Restarting on
page 11-22
Changing Event Levels This function allows you to change the level of errors that
occur in the EtherCAT Slave Terminal.
11-8 Changing Event
Levels on page 11-24
Resetting Errors This function allows you to use the Sysmac Studio to
reset errors that occur in the EtherCAT Slave Terminal.
11-9 Resetting Errors
on page 11-27
Function Overview Reference
