Omron NX-ECC201 User Manual

13 - 39
13 Troubleshooting
NX-series EtherCAT Coupler Unit User’s Manual (W519)
13-3 Checking for Errors and Troubleshooting on the Sysmac Stu-
dio
13
13-3-2 Event Codes for Errors and Troubleshooting Procedures
Event name Restart Executed Event code 90420000 hex
Meaning A restart was executed.
Source EtherCAT Master Function Mod-
ule
Source details EtherCAT Cou-
pler Unit
Detection
timing
When Slave
Terminal or NX
Unit is restarted
Error
attributes
Level Information Recovery --- Log category Access
Effects User program Continues. Operation Operation starts after the restart is executed.
Sys-
tem-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
A restart command was received. --- ---
Attached
information
Attached information 1: Type of restart
0: The EtherCAT Slave Terminal was restarted.
Precautions/
Remarks
None
Event name Memory All Cleared Event code 90430000 hex
Meaning The Unit settings were cleared.
Source EtherCAT Master Function Mod-
ule
Source details EtherCAT Cou-
pler Unit
Detection
timing
When
commanded
from user
Error
attributes
Level Information Recovery --- Log category Access
Effects User program Continues. Operation The Unit settings were cleared.
Sys-
tem-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The non-volatile memory in the
EtherCAT Coupler Unit was
cleared.
--- ---
Attached
information
Attached information 1 and 3: Unit number of the NX Unit where the Clear All Memory operation was per-
formed
Attached information 2 and 4: Execution results
0: Successful
1: Hardware error
2: Initialization failed
3: Initialization not possible
Precautions/
Remarks
Refer to the attached information for the results of the Clear All Memory operation.
