Event name Stuck-at-high Detected at Safety Output Event Code 65280000 hex
Meaning It was detected that the safety output terminal is stuck ON.
Source Depends on where the Sysmac
Studio is connected and the sys-
tem configuration.
Source details NX Unit Detection tim-
ing
During refresh-
ing
Error attrib-
utes
Level Minor fault Recovery When safety
output terminal
goes inactive
after cause of
error is re-
moved
Log category System
Effects User program Continues. Operation The safety output terminal retains the safe state
until the error is cleared.
System-de-
fined varia-
bles
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
The positive power supply line is
in contact with the output signal
line.
Check the external wiring. Set the parameters and wire the
system considering the correc-
tions that are given on the left.
The output power supply is out-
side the specifications.
Check the output power supply.
The internal circuit is faulty. Cycle the power supply. If the er-
ror occurs again, replace the
Unit.
If cycling the power supply re-
stores normal operation, there
may be excessive noise near the
Unit. Implement noise counter-
measures.
A memory error or signal error
occurred due to a transient
cause, such as a software error
or excessive noise.
Attached in-
formation
Attached information 1: Terminal number
Precautions/
Remarks
None
