Search Options
Item Function
Match case When this option is selected, searches are case sensitive.
Match whole word When selected, only exact string matches are returned.
Search up When selected, the search is performed backward from the cursor position.
l
Button Functions
Item Function
Search Next Performs a search according to the selected options.
Search All Searches all items and lists the results in the Output Tab Page.
Replace Performs a replace according to the selected options.
Replace All Replaces all items and lists the results in the Output Tab Page.
Cancel Cancels the current search and replace operation.
6-5-8
Safety Task Settings
This section describes the procedures that are used to select the programs to execute in the safety
task and the execution order of the selected programs. It also describes how to set the task period of
the safety task.
Refer to S
e
ction 8 Calculating Safety Reaction Times on page 8 - 1 for details on safety tasks.
Program Assignments
The program assignment settings are used to assign the programs to the safety task and set the pro-
gram execution order.
The programs that are assigned to the task are executed in the specified order
.
1 Double-click Task Settings
under Configurations and Setup in the Multiview Explorer.
2 Click the Program Assignment Settings Button (
) in Safety Task Settings Tab Page in the
Edit Pane.
3 The buttons shown within the red frame below allow you to change the program assignments
and their execution order.
6 Programming
6 - 66
NX-series Safety Control Unit User's Manual (Z930)
