Item Name Function
(e) Output Tab Page The Output Tab Page shows the results of building.
Watch Tab Page The Watch Tab Page shows the monitor results of the Simulator or the online Safety
CPU Unit.
Build Tab Page The Build Tab Page shows the results of program checks and building.
Search and Re-
place Results
T
ab Page
The Search and Replace Results Tab Page shows the results when Search All or Re-
place All is executed.
(f) Filter Pane The Filter Pane allows you to search for color codes and for items with an error icon.
The results are displayed in a list.
This manual describes only the functions and operations of the Sysmac Studio that are related to the
safety control system.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for details on Sysmac Studio
operation.
