Omron NX-SID Series - A-6-2 NX-SID800 Safety Input Unit

Appendix
A - 64
NX-series Safety Control Unit User’s Manual (Z930)
IO Power Supply
Error Flag
BOOL R IO Power
Supply
Error Flag
This flag indicates the status of
the I/O power supply voltage.
0: The I/O power supply voltage
is normal.
1: The I/O power supply voltage
is incorrect or the I/O power sup-
ply is OFF.
0 ---
Standard Input 2nd
Byte
BYTE R Standard
Input 2nd
Byte
--- 00 hex ---
Si00 Status BOOL R Si00 Status Gives the status of safety input
terminal 00.
0: Error
1: No error
0 ---
Si01 Status BOOL R Si01 Status Gives the status of safety input
terminal 01.
0: Error
1: No error
0 ---
Si02 Status BOOL R Si02 Status Gives the status of safety input
terminal 02.
0: Error
1: No error
0 ---
Si03 Status BOOL R Si03 Status Gives the status of safety input
terminal 03.
0: Error
1: No error
0 ---
A-6-2 NX-SID800 Safety Input Unit
Port
Data
type
R/W Name Description Default
Corre-
sponding
port name
Standard Input 1st
Word
WORD R Standard
Input 1st
Word
--- 0000
hex
---
Si00 Logical Value BOOL R Si00 Logi-
cal Value
Gives the status of safety input ter-
minal Si00.
0: OFF, 1: ON
0Same
Si01 Logical Value BOOL R Si01 Logi-
cal Value
Gives the status of safety input ter-
minal Si01.
0: OFF, 1: ON
0Same
Si02 Logical Value BOOL R Si02 Logi-
cal Value
Gives the status of safety input ter-
minal Si02.
0: OFF, 1: ON
0Same
Si03 Logical Value BOOL R Si03 Logi-
cal Value
Gives the status of safety input ter-
minal Si03.
0: OFF, 1: ON
0Same
Si04 Logical Value BOOL R Si04 Logi-
cal Value
Gives the status of safety input ter-
minal Si04.
0: OFF, 1: ON
0Same
Port
Data
type
R/W Name Description Default
Corre-
sponding
port name
