Item Specification
Operating environment Ambient operating tem-
perature
0 to 55°C
Ambient operating hu-
midity
10% to 95% (with no condensation or icing)
Atmosphere Must be free from corrosive gases.
Ambient storage temper-
ature
−25 to 70°C (with no condensation or icing)
Altitude 2,000 m max.
Pollution degree Pollution degree 2 or less: Conforms to JIS B 3502
and IEC 61
131-2
Noise immunity Conforms to IEC 61
131-2, 2 kV (power supply line)
Insulation class CLASS III (SELV)
Overvoltage category Category II: Conforms to JIS B 3502 and IEC 61131-2
EMC immunity level Zone B
Vibration resistance Conforms to IEC 60068-2-6
5 to 8.4 Hz with amplitude of 3.5 mm
8.4 to 150 Hz, acceleration of 9.8 m/s
2
100 min. in each X, Y
, and Z directions (10 sweeps of
10 min. each = 100 min. total)
Shock resistance Conforms to IEC 60068-2-27
147 m/s
2
, 3 times in each X, Y, and Z directions
Installation method DIN T
rack (IEC 60715 TH35-7.5/TH35-15)
Individual Specifications
This section provides the individual specifications of the Safety CPU Unit.
l
Datasheet Items for Safety CPU Unit
The following table gives the meaning of the datasheet items for the Safety CPU Unit.
Item Description
Maximum number of safety
I/O points
This is the number of safety I/O points that Safety CPU Unit can control.
Program capacity This is the capacity of the safety programs in the Unit.
Number of safety I/O connec-
tions
*1
This is the maximum number of Safety I/O connections that can be set to this
Unit. The value is the total number of CIP Safety originator connections, CIP
Safety target connections, and FSoE master connections.
Number of CIP Safety origi-
nator connections
*2
This is the maximum number of CIP Safety originator connections that can be
set to this Unit.
Number of CIP Safety target
connections
*2
This is the maximum number of CIP Safety target connections that can be set
to this Unit.
Number of originators that
can be connected with a mul-
ti-cast connection
When this unit is a CIP Safety target, it is the number of CIP Safety origina-
tors that can be connected with a multi-cast connection by a single CIP Safe-
ty target connection.
Number of FSoE master con-
nections
It is the maximum number of FSoE master connections that can be config-
ured to this unit.
I/O refreshing method The I/O refreshing methods that are used by the Unit.
2 Specifications
2 - 3
NX-series Safety Control Unit User's Manual (Z930)
2-1 Safety CPU Unit
2
2-1-1 Models and Specifications
