Omron NX-SID Series - NX-SOH200 Safety Output Unit

Appendix
A - 66
NX-series Safety Control Unit User’s Manual (Z930)
Si04 Status BOOL R Si04 Status Gives the status of safety input ter-
minal 04.
0: Error
1: No error
0---
Si05 Status BOOL R Si05 Status Gives the status of safety input ter-
minal 05.
0: Error
1: No error
0---
Si06 Status BOOL R Si06 Status Gives the status of safety input ter-
minal 06.
0: Error
1: No error
0---
Si07 Status BOOL R Si07 Status Gives the status of safety input ter-
minal 07.
0: Error
1: No error
0---
A-6-3 NX-SOH200 Safety Output Unit
Port
Data
type
R/W Name Description Default
Corre-
sponding
port name
Standard Input 1st
Byte
BYTE R Standard
Input 1st
Byte
--- 00 hex ---
So00 Monitor Value BOOL R So00 Moni-
tor Value
Gives the status of safety output
terminal So00.
0: OFF, 1: ON
0 So00 Out-
put Value
So01 Monitor Value BOOL R So01 Moni-
tor Value
Gives the status of safety output
terminal So01.
0: OFF, 1: ON
0 So01 Out-
put Value
Safety Connection
Status
BOOL R Safety Con-
nection Sta-
tus
This flag indicates when a safety
connection is active. Use it for an
input to the Activate terminal on a
safety FB or for safety connec-
tion/disconnection applications.
0Same
Safety Output Termi-
nal Status
BOOL R Safety Out-
put Termi-
nal Status
This flag indicates the status of the
safety output terminals.
0: An error has occurred on one of
the safety output terminals.
1: All of the safety output terminals
are normal (no errors).
0Same
Unit Normal Status BOOL R Unit Nor-
mal Status
This flag indicates the status of the
Unit.
0: An error has occurred.
1: Normal (no errors)
0---
Port
Data
type
R/W Name Description Default
Corre-
sponding
port name
