A-2 NX Objects
In this manual, NX objects are described with the following format.
A-2-1 Format of NX Object Descriptions
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
Index (hex): This is the index of the NX object that is expressed as a four-digit hexadecimal
number.
Subindex (hex): This is the subindex of the NX object that is expressed as a two-digit hexadeci-
mal number.
Object name: This is the name of the object. For a subindex, this is the name of the subindex.
Default value: This is the value that is set by default.
Data range: For a read-only (RO) NX object, this is the range of the data you can read. For a
read-write (RW) NX object, this is the setting range of the data.
Unit: The unit is the physical units.
Data type: This is the data type of the object.
Access: This data tells if the object is read-only or read/write.
RO: Read only
RW: Read/write
I/O allocation: This tells whether I/O allocation is allowed.
Data attribute: This is the timing when changes to writable NX objects are enabled.
Y: Enabled by restarting
N: Enabled at all times
―: Write-prohibited
