Omron NX-SID800

7 - 51
7 Programming
NX-series Safety Control Unit User’s Manual (Z930)
7-5 Programming Operations
7
7-5-4 FBD Programming
Use the following procedure to delete any unused parameters from a FUN or FB.
Method: Right-click the FUN or FB on the FBD network and select Remove unused FB call parame-
ters from the menu.
All of the unused parameters are deleted.
• Before the Unused Parameters of the FUN or FB Are Deleted
• After the Unused Parameters of the FUN or FB Are Deleted
Use the following procedure to display the input parameters and output parameters of a FUN or FB.
Method: Right-click a FUN or FB on the FBD network and select Update from the menu.
The input parameters and output parameters for the FUN or FB are displayed along with any unused
parameters.
• Before the Input Parameters and Output Parameters of the FUN or FB Are Updated
• After the Input Parameters and Output Parameters of the FUN or FB Are Updated
Deleting Unused Parameters from a FUN or FB
Updating the Input Parameters and Output Parameters of a FUN or
FB
