5-19
5 Setting Up EtherCAT Communications with the Sysmac Studio
NJ/NX-series CPU Unit Built-in EtherCAT Port User’s Manual (W505)
5-4 EtherCAT Master and Slave Parameter Settings
5
5-4-2 Setting EtherCAT Slaves
*1 Displayed only with the NX-series CPU Unit.
*2 Refer to 1-3-1 Performance Specifications for the settable node address range.
*3 Network errors do not occur even if disabled slaves are not present on the EtherCAT network. You can
use them to prepare for future system expansions or to operate without them for the current system.
You can execute a special instruction to enable a disabled slave during system operation. You can also
execute the special instruction to disable a slave during system operation.
*4 With the NJ-series CPU Unit, if you configure the system to connect the EtherCAT Junction Slave and
to synchronize the slaves that have an enabled distributed clock, there must be a slave that provides a
reference clock between the Master and the first EtherCAT Junction Slave. Or, the first EtherCAT Junc-
tion Slave must provide a reference clock.
A CPU Unit with unit version 1.04 or later and Sysmac Studio version 1.05 or higher are required
to disable EtherCAT slaves with the special instruction.
Reference Clock Not
allowed.
Displays whether the slave provides a reference clock.
*4
Exist is displayed if the slave provides a reference clock.
Not exist is displayed if the slave does not provide a refer-
ence clock.
Setting Parameters
OK If a slave has an initial parameter setting function, Setting
is displayed.
If a slave does not have an initial parameter setting func-
tion, “---” is displayed.
To edit the settings, click the Edit Setting Parameters
Button.
Backup Parameter Settings OK If a slave has a backup parameter setting function, Setting
is displayed.
If a slave does not have a backup parameter setting func-
tion, “---” is displayed.
To edit the settings, click the Edit Backup Parameter
Settings Button.
Name Editing Remarks
To Next Page
