Related Manuals
NJ/NX-series CPU Unit Built-in EtherCAT Port User’s Manual (W505)
Related Manuals
The followings are the manuals related to this manual. Use these manuals for reference.
Manual name Cat. No. Model numbers Application Description
NX-series CPU Unit
Hardware User’s Manual
W535 NX701- Learning the basic specifi-
cations of the NX701 CPU
Units, including introduc-
tory information, designing,
installation, and mainte-
nance.
Mainly hardware informa-
tion is provided.
An introduction to the entire NX701 system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
NX-series NX102 CPU
Unit Hardware User's
Manual
W593 NX102- Learning the basic specifi-
cations of the NX102 CPU
Units, including introduc-
tory information, designing,
installation, and mainte-
nance.
Mainly hardware informa-
tion is provided.
An introduction to the entire NX102 system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
NX-series NX1P2 CPU
Unit Hardware User's
Manual
W578 NX1P2- Learning the basic specifi-
cations of the NX1P2 CPU
Units, including introduc-
tory information, designing,
installation, and mainte-
nance.
Mainly hardware informa-
tion is provided.
An introduction to the entire NX1P2 system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
NJ-series CPU Unit
Hardware User’s Manual
W500 NJ501-
NJ301-
NJ101-
Learning the basic specifi-
cations of the NJ-series
CPU Units, including intro-
ductory information,
designing, installation, and
maintenance.
Mainly hardware informa-
tion is provided.
An introduction to the entire NJ-series system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
NJ/NX-series CPU Unit
Software User’s Manual
W501
NX701-
NX102-
NX1P2-
NJ501-
NJ301-
NJ101-
Learning how to program
and set up an NJ/NX-
series CPU Unit.
Mainly software informa-
tion is provided.
The following information is provided on a Con-
troller built with an NJ/NX-series CPU Unit.
• CPU Unit operation
• CPU Unit features
• Initial settings
• Programming based on IEC 61131-3 lan-
guage specifications
NX-series NX1P2 CPU
Unit Built-in I/O and
Option Board User's
Manual
W579 NX1P2- Learning about the details
of functions only for an NX-
series NX1P2 CPU Unit
and an introduction of func-
tions for an NJ/NX-series
CPU Unit.
Of the functions for an NX1P2 CPU Unit, the fol-
lowing information is provided.
• Built-in I/O
• Serial Communications Option Boards
• Analog I/O Option Boards
An introduction of following functions for an
NJ/NX-series CPU Unit is also provided.
• Motion control functions
• EtherNet/IP communications functions
• EtherCAT communications functions
To Next Page
