ESI file versions that are lower than ESI version-1.0.1 specifications are not supported. If you
install an ESI file version that is not supported, a message saying that you cannot use the slave
is displayed by the Sysmac Studio.
The NJ/NX-series CPU Units do not support variables with some of the data types that are
defined in ETG.1020. If variables with any unsupported data types are included in the slave infor-
mation (ESI), you cannot use the slave.
The following tables gives the data types that are supported by different Sysmac Studio versions.
* With Sysmac Studio version 1.06, 1.07, or 1.08, you can read ESI files and assign device variables. How-
ever, you cannot monitor them in the I/O Map.
If variables with any of these data types are included in the slave information (ESI), a message
saying that you cannot use the slave is displayed in the ESI Library Dialog Box of the Sysmac
Studio.
Data Type
Sysmac Studio Ver.
1.09 or higher 1.08 1.07 or lower
BIT1, BIT2, BIT3, BIT4, BIT5, BIT6, BIT7,
and BIT8
Supported. Supported. Not supported.
BITARR8, BITARR16, and BITARR32 Supported. Supported. Not supported.
ARRAY[0..n] OF BYTE Supported.
Not supported.
*
Not supported.
*
ARRAY[0..n] OF UINT Supported.
Not supported.
*
Not supported.
*
INT24, INT40, INT48, and INT56 Not supported. Not supported. Not supported.
UINT24, UINT40, UINT48, and UINT56 Not supported. Not supported. Not supported.
STRING(n) Not supported. Not supported. Not supported.
To Next Page
