9-31
9-4 Setting the Mode
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
9
Operation
7. Returning to Parameter Write Mode
8. Restart the power supply to the drive
Precautions for Correct Use
The items that are limited depend on the mode.
If the Front Panel Parameter Write Selection (Pn617) is set to 1, the parameter set value is
automatically written to EEPROM when changed.
Refer to the Front Key Protection Setting (Pn535) in "8-6 Extended Parameters" (P.8-47) for
details on the front panel lock function.
Press and hold the key for 5 seconds or longer until
is displayed.
The bar indicator will increase.
Writing will start. (This display will appear only momentarily.)
This indicates a normal completion. In addition to this display,
either or may be displayed.
If is displayed, writing has been completed normally,
but some of the changed parameters will be valid only after the
power supply has been turned OFF and ON again. Turn OFF the
drive power supply and then turn it ON again.
will be displayed if there is a write alarm. Write the
data again.
Key
operation
Display example Explanation
Key
operation
Display example Explanation
Press the key to return to Parameter Write Mode.
To Next Page
