2-34
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
3-phase 200 VAC: R88D-KT75H (7.5 kW)
Wall Mounting
External dimensions
Mounting dimensions
250
235
220
90
90
90
71
26
210 11
210
90
90
90
71
26
11
233
334
3.5
R2.6
R2.6
R2.6
φ5.2
φ5.2
φ5.2
φ5.2
R2.6 R2.6
R2.6
70
2.5
1
10-M4
235
45
220
27
180
233
