Specifications
10
10.6
Drive
Exterior
and
Mounting
Dimensions
SIEPYEUOQ2A01A
AC
Drive
Q2A
T
echnical
Manual
383
■
4371
Figure
10.17
Exterior
and
Mounting
Dimensions
Diagram
8
T
able
10.34
400
V
Class
(UL
T
ype
1)
Model
Dimensions
mm
(in.)
Weight
kg
(lb.)
W
H
D
D1
D2
W1
W2
W3
(max.)
H0
H1
H2
H3
H5
t1
t2
d
4371
444
(17.48)
1045
(41.14)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
18
(0.709)
800
(31.50)
757
(29.80)
28
(1.102)
245
(9.65)
30
(1.181)
4.5
(0.177)
4.5
(0.177)
M12
130
(286.60)
382
384
