10.8 Peripheral Devices and Options
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 389
◆ Keypad Options
Name Model Purpose
LCD Operator Extension Cable
WV001 (1 m [3.3 ft] length)
WV003 (3 m [9.8 ft] length)
To connect the keypad and drive.
This option is an RJ-45, 8-pin straight-through UTP CAT5e cable.
Installation Support Set A 900-192-933-001
To attach the keypad to the control panel. This option uses screws.
Installation Support Set B 900-192-933-002
To attach the keypad to the control panel. This option uses nut clamps.
Use this option when weld studs are located in the control panel.
◆ Attachments
Name Model Purpose
External Heatsink Mount Kit
900-193-209-001
900-193-209-002
900-193-209-003
Use this option to install the heatsink outside of the control panel.
Note:
When you use external heatsink mounting, it may be necessary to decrease the current.
UL Type 1 Kit
900-192-121-001
900-192-121-002
900-192-121-003
900-192-121-004
900-192-121-005
To change an open chassis type (IP20) drive to an enclosed wall-mounted type (UL Type 1) drive.
Braking Resistor Installation
Attachment
EZZ020805A
To install a braking resistor to a drive.
External Mounting Attachment
for Braking Unit Fin
EZZ021711A
To install the heatsink for the braking unit outside of the control panel.
◆ Engineering Tools
Name Model Purpose
Q2edit -
To use a PC to configure drives and manage parameters.
Q2dev -
To use a PC to do advanced drive programming.
◆ Option Cards
Name Model Purpose Document No.
Complementary Type PG PG-B3
This option is for use with PG V/f Control and OLVector control methods. The
drive detects motor rotation speed from the pulse generator as feedback. The
drive can then enable control of the output frequency keep a constant motor
speed.
• Complementary output PG support
• A, B, and Z pulse (Three-phase pulse) input
• Maximum input frequency: 50 kHz
• Pulse monitor output: Open-collector (24 V, maximum of 30 mA)
• Encoder power supply: 12 V, maximum 200 mA current.
TOBPC73060075
Motor PG Feedback Line Driver
Interface
PG-X3
This option is for use with CLVector, PG V/f Control, and PM CLVector
control methods. The drive detects motor rotation speed from the pulse
generator as feedback. The drive can then enable control of the output
frequency keep a constant motor speed.
• RS-422 output encoder support
• A, B, and Z pulse (differential pulse) input
• Maximum input frequency: 300 kHz
• Pulse monitor: Equivalent to RS-422 level
• Encoder voltage output: 5 Vor 12V, maximum 200 mA current
TOBPC73060076
