11.7 F: OPTIONS
426 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-50
(03C1)
DNet MAC Address
Sets the MAC address for DeviceNet communication. Restart the drive after you change
this setting.
Note:
Be sure to set a MAC address that is different than all other node addresses. Do not
set this parameter to 0. Incorrect parameter settings will cause AEr [Station Address
Setting Error] errors and the MS LED on the option will flash.
0
(0 - 64)
656
F6-51
(03C2)
DNet Baud Rate
Sets the DeviceNet communications speed. Restart the drive after you change this
setting.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
3 : Adjustable from Network
4 : Detect Automatically
0
(0 - 4)
656
F6-52
(03C3)
DNet PCA Setting
Sets the format of data that the DeviceNet communication master sends to the drive.
21
(0 - 255)
656
F6-53
(03C4)
DNet PPA Setting
Sets the format of data that the drive sends to the DeviceNet communication master.
71
(0 - 255)
656
F6-54
(03C5)
DNet Idle Fault
Detection
Sets the function to detect EF0 [Option Card External Fault] when the drive does not
receive data from the DeviceNet master.
0 : Enabled
1 : Disabled, No Fault Detection
2 : Vendor Specific
3 : RUN Forward
4 : RUN Reverse
0
(0 - 4)
657
F6-55
(03C6)
DNet Baud Monitor
Sets the function to see the actual DeviceNet communications speed using the keypad.
This parameter functions as a monitor only.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
0
(0 - 2)
657
F6-56
(03D7)
DNet Speed Scale Factor
Sets the speed scale for DeviceNet communication.
0
(-15 - +15)
657
F6-57
(03D8)
DNet Current Scale
Factor
Sets the current scale of the DeviceNet communication master.
0
(-15 - +15)
657
F6-58
(03D9)
DNet Torque Scale
Factor
Sets the torque scale of the DeviceNet communication master.
0
(-15 - +15)
657
F6-59
(03DA)
DNet Power Scaling
Sets the power scale of the DeviceNet communication master.
0
(-15 - +15)
657
F6-60
(03DB)
DNet Voltage Scale
Sets the voltage scale of the DeviceNet communication master.
0
(-15 - +15)
657
F6-61
(03DC)
DNet Time Scale
Sets the time scale of the DeviceNet communication master.
0
(-15 - +15)
658
F6-62
(03DD)
DNet Heartbeat Interval
Sets the heartbeat for DeviceNet communication. Set this parameter to 0 to disable the
heartbeat function.
0
(0 - 10)
658
F6-63
(03DE)
DNet Network MAC ID
Sets the function to see the actual DeviceNet MAC address using the keypad. This
parameter functions as a monitor only.
0
(0 - 63)
658
F6-64 to F6-67
(03DF - 03E2)
DynOut.Ass109 P1 to P4
Sets Configurable Outputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
658
F6-68 to F6-71
(03E3, 03E4,
03C7, and
03C8)
DynIn.Ass159 P1 to 4
Sets Configurable Inputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
658
F6-72
(081B)
PowerLink Address
Sets the node ID for PowerLink communication.
Note:
Set a node address that is unique. Do not set this parameter to a value of 0.
0
(0 - 255)
658
