Omron Q2A Series Technical Manual

Parameter List
11
11.19 Defaults by Drive Model and Duty Rating ND/HD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 491
Parameter Unit
Drive Model
4031 4038 4044 4060
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 11 15 15 18.5 18.5 22 22 30
b8-03 eSave Filter Time s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 eSave Coef. Value - 140.88 126.26 126.26 115.74 115.74 103.58 103.58 92.54
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
0.053 0.076 0.076 0.138 0.138 0.165 0.165 0.220
C6-02 Carrier Frequency Selection - 1 7 1 7 1 7 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 19.9 26.5 26.5 32.9 32.9 38.6 38.6 52.3
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 1.7 1.6 1.6 1.67 1.67 1.7 1.7 1.8
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 5.6 7.6 7.6 7.8 7.8 9.2 9.2 10.9
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 0.922 0.55 0.55 0.403 0.403 0.316 0.316 0.269
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 19.6 17.2 17.2 20.1 20.1 23.5 23.5 20.7
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 385 440 440 508 508 586 586 750
E5-01 PM Mot Code Selection - 123D 123D 123E 123E 123F 123F 1240 1240
L2-02 RideThrough Time@Power Loss s 2 2 2 2 2 2 2 2
L2-03 Min Baseblck Time s 0.9 1 1 1 1 1 1 1.1
L2-04 Powloss Ramp Time@recovery s 0.3 0.6 0.6 0.6 0.6 0.6 0.6 0.6
L2-05 UV Detection Lvl (Uv1) - 380 380 380 380 380 380 380 380
L3-24 Acc@Rated Torque s 0.265 0.244 0.244 0.317 0.317 0.355 0.355 0.323
L8-02 Overheat Alm Level °C 100 100 120 120 120 120 130 137
L8-09 Ground Fault Selection - 1 1 1 1 1 1 1 1
L8-38 Carrier Reduction Mode - 2 2 2 2 2 2 2 2
n1-01 HuntPrev Selection - 2 2 2 2 2 2 2 2
n1-03 HuntPrev Time Constant ms 10 10 10 10 10 10 10 10
n1-16 HuntPrev HiFc Gain - 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 0.265 0.244 0.244 0.317 0.317 0.355 0.355 0.323
n8-11 Observ.Calc Gain2 - 50.0 50.0 50.0 50.0 50.0 50.0 50.0 50.0
Parameter Unit
Drive Model
4075 4089 4103 4140
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 30 37 37 45 45 55 55 75
b3-04 SpSrch V/F Gain % 100 100 100 100 100 80 80 80
b3-06 Speed Curr Lev1 for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.7
b3-08 Speed ACR PGain for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.8
b3-26 Dir. Determ. Level - 1000 1000 1000 1000 1000 1000 1000 1000
b8-03 eSave Filter Time s 0.50 0.50 0.50 0.50 0.50 2.00 2.00 2.00
b8-04 eSave Coef. Value - 92.54 76.32 76.32 71.56 71.56 67.2 67.2 46.2
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
0.220 0.273 0.273 0.333 0.333 0.490 0.49 0.90
